| model | al50 | ||
| fluid | air | ||
| maximum operating pressure | 1.0 mpa | ||
| oil capacity (cm3) | 135 | ||
| ambient and fluid temperature | ?5 to 60c (with no freezing) | ||
| Bowl guard | standard | ||
| Weight | 5.07063 lb |
| Port size | 3/4, 1 | ||
| proof pressure | 1.5 mpa | ||
| note)minimum dripping flow rate ( /min (anr)) | 190 | ||
| recommended lubricant | class 1 turbine oil (iso vg32) | ||
| bowl material | polycarbonate | ||
| weight (kg) | 1.06 |
