| body | brass | ||
| Electrical connection | din en 175301-803 | ||
| fluid temperature imperial temperature fahrenheit min to max range | -4 ... 194 °f | ||
| inner parts | brass | ||
| Manual override | option installed | ||
| operating pressure pressure bar min to max range | 0.5 ... 40 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 122 °f | ||
| orifice metric | 20 mm | ||
| Protection class | en 60529 ip65 | ||
| seat seal | nbr |
| coil code | 9,151 | ||
| Flow direction | fixed | ||
| fluid temperature temperature celsius min to max range | -20 ... 90 °c | ||
| kv value flow cubicmeterperhour | 7 m³/h | ||
| maximum fluid temperature temperature celsius | 90 °c | ||
| operating pressure psi pressure psi min to max range | 7 ... 580 psi | ||
| operating temperature temperature celsius min to max range | -20 ... 50 °c | ||
| Port size | g3/4 | ||
| range | 85,360 | ||
| valve operation | 2/2 |
