| design code | b : valve plate | ||
| paint | 0a : primer per spec 209-13a | ||
| displacement options | 0 : as given in code title | ||
| drain ports size & location | a : .750-16 unf-2b sae o-ring port - top (housing) | ||
| output shaft | aa : 13 tooth 16/32 spline, shaft extension 41.1 [1.62] | ||
| motors | aajaada00cn0a0b |
| identification | 0 : standard | ||
| special features | aj : 6.20 bar [90.0 lbf/in2] static seal with adaptor | ||
| auxiliary mounting features (rear) | 0 : none | ||
| main ports size & location | d : 1.3125-12 un-2b sae o-ring ports - top | ||
| code title | aaj : 40.6 cm3/r [2.48 in3/r] fixed displacement axial piston motor |
