| motors | h motor | ||
| Series | h0 : h series motor | ||
| Mounting type | ma : 2 bolt std - 82.50 [3.248] dia. x 8.13 [.320] pilot, 13.59 [.535] dia. mounting holes on 106.35 [4.187] dia. b.c., w/o o-ring groove | ||
| port type | af : g 1/2 bsp straight thread ports | ||
| gerotor options | 0 : none | ||
| seal options | 07 : high pressure shaft seal | ||
| valve options | 00 : none | ||
| special assembly instructions | 0 : none | ||
| customer id./nameplate options | 00 : none specified |
| product | m : motor | ||
| displacement | 028 : 46 cm3/r [2.8 in3/r] | ||
| output shaft | 39 : 25.00 [.984] dia. straight (k6), 8.00 [.315] key, m8 x 1.25-6h hole in shaft end | ||
| case flow options | 02 : g 1/4 bsp straight thd port (end cap) | ||
| shaft options | 0 : none | ||
| speed sensor options | 00 : none | ||
| special features (hardware) | 00 : none specified | ||
| paint/packaging options | aa : primer low gloss black | ||
| design code | j : nine (9) |
