| seal material | acrylonitrile butadiene rubber | ||
| Weight | 0.23 kg | ||
| oil content of compressed air max. | 1 mg/m³ | ||
| max. particle size | 50 µm | ||
| max. medium temperature | 50 °c | ||
| max. ambient temperature | 50 °c | ||
| regulation range max. | 8 bar | ||
| working pressure max | 10 bar | ||
| compressed air connection gauge port | Ø 6x1 | ||
| compressed air connection input | Ø 12, special base plate | ||
| certificates | free of substances that impair surface wetting in the coating process |
| Housing Material | polyamide fiber-glass reinforced, polyoxymethylene | ||
| qn 1▶2 | 2100 l/min | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| Medium | compressed air | ||
| min. medium temperature | -15 °c | ||
| min. ambient temperature | -15 °c | ||
| regulation range min. | 0.8 bar | ||
| working pressure min. | 2 bar | ||
| compressed air connection type input | base plate connection, push-in fitting | ||
| actuating element | screw with wrench flats | ||
| Type | poppet valve |
