| screw-in cartridge valves | 1ceb90; danfoss screw-in cartridge valve; overcenter; fully balanced | ||
| Adjustment | -f : screw adjustment | ||
| pressure range | -35 : 200 - 350 bar ; std setting - 210 bar | ||
| pilot ratio | 4 : 4;1 | ||
| special features | no special features |
| Series | 1ceb90 : fully balanced over center valve -pilot assisted relief with check valve-90 l/min - catridge only | ||
| Port size | cartridge only | ||
| Seal | s : nitrile (for use with most industrial hydraulic oils) | ||
| body material | aluminum (for pressure setting < 210 bar) |
