| Body Material: | Cast Iron | ||
| Charge Pump Included: | NO | ||
| Configuration: | Single | ||
| Energy Recovery Capability: | YES | ||
| For Fluid Type: | Standard Hydraulic Fluid | ||
| Maximum Flow Rate: | 17.56 Gal/min, 66,5 L/min | ||
| Maximum Operating Pressure: | 420 bar, 6090 psi | ||
| Maximum Operating Speed: | 4600 RPM | ||
| Minimum Kinematic Viscosity: | 8 cSt/ 37.3 SUS | ||
| Media: | HYDRAULIC | ||
| Port Connection: | SAE | ISO | BSPP | ||
| Port Location: | Rear Ports | ||
| Direction of Rotation: | Clockwise | Counter Clockwise | Bi-Rotational | ||
| Shaft Type: | SAE | ISO | |
| Drain Option: | YES | ||
| Circuit Path: | OPEN | ||
| Control Method: | NO | ||
| Filter Included: | NO | ||
| Maximum Displacement: | 1.16 inch3/rev, 19 (cm3/rev) cm3/rev | ||
| Maximum Noise Level: | 80 dBA | ||
| Radial Load Capacity: | 400 kg, 880 lb | ||
| Maximum Kinematic Viscosity: | 1000 cSt / 4664 SUS SUS | ||
| Weight: | 11 kg kg (Max), 24.2 lb (Max) | ||
| Mounting Option: | SAE | ISO | CETOP | CARTRIDGE | ||
| Port Type: | STRAIGHT THREADED | ||
| Pump Type: | Fixed, PISTON | ||
| Sensor Type: | Speed | Rotation | ||
| Thru-Drive Capability: | NO |
