| reduced power dc | 5 w | ||
| thermal insulation class of the actuator | h | ||
| coil size | 20 mm | ||
| coil type | placed on top | ||
| electrical connection position | in direction of flow left | ||
| electrical connection number of contacts | 2 + grounding conductor | ||
| switch time close max. | 17 ms | ||
| switch time open max. | 15 ms | ||
| switch function | on/off | ||
| main valve operating principle | piston | ||
| actuator type | plunger valve | ||
| main valve orifice 1 (inch) | 5/64 inch | ||
| kv value (water) | 0,11 m3/h | ||
| certification type | food - fda-compliant | ||
| sealing toward outside material | epdm (ethylene-propylene-diene rubber) | ||
| seat seal material category | elastomer | ||
| temperature environment min | -30 °c | ||
| temperature medium min | -30 °c | ||
| nominal pressure min | 0 bar | ||
| dc voltage | yes | ||
| voltage tolerance positive | 10 % | ||
| voltage min / rated voltage | 24 v | ||
| port connection 2 thread marking | 1/8 | ||
| port connection 2 type | flanged | ||
| port connection 1 thread type | npt | ||
| port connection 1 type | flanged | ||
| valve function number of switching positions | 2 | ||
| Customscode | 84818079 |
| rated power dc | 5 w | ||
| coil wiring overvoltage protection | without | ||
| coil insulation material (encasement) | epoxy | ||
| protection type ip (max. with suitable connector) | ip65 | ||
| cable plug in delivery | not included | ||
| nominal operation/duty cycle | 100 % | ||
| switch time close min | 10 ms | ||
| switch time open min | 8 ms | ||
| valve construction | valve complete | ||
| operation | direct-acting | ||
| Type | 7,011 | ||
| main valve orifice 1 (p) (mm) | 2 mm | ||
| rated power consumption | 5 w | ||
| approval type | material-approval-foods seal materials | ||
| seat seal material | epdm (ethylene-propylene-diene rubber) | ||
| temperature environment max | 75 °c | ||
| temperature medium max | 100 °c | ||
| nominal pressure max (liquid) | 6,5 bar | ||
| main valve wetted material | stainless steel | ||
| voltage tolerance negative | 10 % | ||
| voltage max / rated voltage | 24 v | ||
| port connection 2 flange | bürkert flange 20 x 20 version a1 | ||
| port connection 2 thread type | npt | ||
| port connection 1 flange | bürkert flange 20 x 20 version a1 | ||
| port connection 1 thread marking | 1/8 | ||
| Valve function | b - normally open - inlet port 1 (p/no) | ||
| fluidic port connection number | 2 |
