| ean | 4015081785025 | ||
| product height | 750 mm | ||
| Product weight | 12.24 kg | ||
| special features | k2x240/1 (5th conductor can be retrofitted) sides closed, but with full area knockout, top and bottom closed with fl4-x gland plates integrated pressure-relief mechanism for short-circuits fuse switch-disconnector fitted to steel mounting plate fixing straps for wall fixing sealable cover fasteners terminal for connecting the 4th conductor (pen) | ||
| housing depth | 275 mm | ||
| construction size (fuse inserts) | nh3 | ||
| functions | enclosures with devices fitted | ||
| number of poles | three-pole | ||
| housing of equipment fuse switch disconnector | with safety switch disconnector | ||
| used with | xenergy safety ci individual enclosures with nh fuse switch-disconnectors enclosures with devices fitted |
||
| cover/door type | transparent | ||
| rated operational current | 550 a | ||
| rated insulation voltage (ui) | 1000 v |
| product length/depth | 275 mm | ||
| product width | 375 mm | ||
| compliances | rohs conform | ||
| housing height | 750 mm | ||
| rated operating voltage (ue) at ac - max | 690 v | ||
| unit type | stand-alone device | ||
| voltage rating at ac | 690 v ac | ||
| Type | enclosures with devices fitted individual enclosures with nh fuse switch-disconnectors xenergy safety ci | ||
| housing width | 375 mm | ||
| fuse cartridge | nh3 | ||
| voltage rating | 690 v ac | ||
| Degree of protection | ip65 other |
