| packaging type | standard | ||
| Application | semiconductor, dc common bus, dc drives, power converters/rectifiers | ||
| class | class ar | ||
| fuse shape | square body, slotted offset bolted tags | ||
| watt losses | 30 w | ||
| mounting dimension | m10 | ||
| Color | none | ||
| clearing (i2t) | 13000 at 660 v | ||
| voltage rating | 690 v (iec), 700 v (ul) | ||
| amperage rating | 160 a | ||
| insulated metal gripping lugs (imgl) | no | ||
| interrupt rating | 200 kaic | ||
| compliances | ce marked rohs compliant |
||
| Product weight | 222.5 g | ||
| product height | 67 mm | ||
| ean | 5027590442435 |
| voltage type | ac | ||
| pre arc (i2t) | 1,900 | ||
| breaking capacity | 200 ka | ||
| Type | fuse | ||
| utilization category | ar (accompanied semiconductor protection) | ||
| connection | blade end x blade end | ||
| rated voltage ac | 690 v | ||
| fuse indicator | top fuse status indicator | ||
| fuse type | din 43653 tn/80 type t indicator for micro |
||
| current type | ac | ||
| center-to-center distance of connections | 78 mm | ||
| certifications | ul recognized iec rated |
||
| warranty | not applicable | ||
| product width | 30 mm | ||
| product length/depth | 100 mm | ||
| UPC | 051712254243 |
