| motors | t motor | ||
| Series | t0 : t series motor | ||
| Mounting type | dd : 2 bolt std - 101.60 [4.000] dia. x 6.10 [.240] pilot, 14.35 [.565] dia. mounting holes on 146.05 [5.750] dia. b.c. (sae b) (ductile) | ||
| port type | aa : .875-14 unf-2b sae o-ring ports | ||
| geroler options | 0 : none | ||
| seal options | 00 : standard seals | ||
| valve options | 00 : none | ||
| special assembly instructions | 0 : none | ||
| customer id./nameplate options | 00 : none specified |
| product | m : motor | ||
| displacement | 040 : 65 cm3/r [4.0 in3/r] | ||
| output shaft | 01 : 25.4 [1.00] dia. straight, woodruff key, .250-20 unc-2b hole in shaft end | ||
| case flow options | 01 : .4375-20 unf-2b sae o-ring port (end cap) | ||
| shaft options | 0 : none | ||
| speed sensor options | 00 : none | ||
| special features (hardware) | 00 : none specified | ||
| paint/packaging options | 00 : no paint | ||
| design code | a : one |
