| Bore diameter | d | 25.40 | mm |
| Total bearing width | T | 19.05 | mm |
| Width Inner ring | B | 20.64 | mm |
| Corner radius inner ring | r1,2 | min.0.8 | |
| Distance pressure point | a | 12.68 | mm |
| Outside diameter | d2 | 62 | mm |
| Inner ring shoulder diameter | d1 | ≈45.8 | |
| Width Outer ring | C | 14.29 | mm |
| Corner radius outer ring | r3,4 | min.1.3 |
