| seal material | fkm | ||
| valve type | 3/2 way | ||
| maximum operating pressure | 8, 5 bar ac/dc | ||
| flow coefficient 1 | 3, 5 l/min | ||
| Port size | 1/4 npt / 1/8 nptf | ||
| function | universal | ||
| Electrical connection | - | ||
| port type | pipe mounting | ||
| orifice size | 2,5 mm | ||
| flow coefficient 2 | 0,15 m³/h | ||
| minimum fluid temperature | -25° c | ||
| coil power consumption | - | ||
| specifications met | - |
| coil specifications met | - | ||
| power supply voltage | - | ||
| media | air, inert gases | ||
| coil temperature range | - | ||
| atex specifications met | - | ||
| body material | 316l stainless steel | ||
| actuation type | direct operated | ||
| seat material | stainless steel | ||
| exhaust orifice size | 2,5 mm | ||
| minimum operating pressure | 0 bar ac/dc | ||
| maximum fluid temperature | +75° c | ||
| insulation class | f 155 °c |
