| function | normally closed | ||
| specifications met | - | ||
| orifice size | 4, 5 mm | ||
| insulation class | h (180 °c) | ||
| maximum operating pressure | 2 bar | ||
| seat material | brass | ||
| Port size | g 1/4 | ||
| body material | brass | ||
| flow coefficient 1 | 7 l/min | ||
| minimum operating pressure | 0 bar | ||
| maximum fluid temperature | 75 °c | ||
| coil power consumption | 9w | ||
| coil specifications met | ce - vde - ukca |
| power supply voltage | 24v dc | ||
| actuation type | direct operated | ||
| atex specifications met | - | ||
| exhaust orifice size | 6, 0 mm | ||
| Electrical connection | 2 p + e plug according to en 175301-803 type a | ||
| valve type | 3/2 way | ||
| port type | pipe mounting | ||
| media | air, inert gases, liquids | ||
| flow coefficient 2 | 0,42 m3/h | ||
| minimum fluid temperature | -10 °c | ||
| seal material | fkm | ||
| coil temperature range | -40°c +50°c |
