| Brand | snr | ||
| Da max - Max shoulder diameter OR | 78,7 mm | ||
| db - Min diameter for Sleeve | 50 mm | ||
| da max - Max shoulder diameter IR | 52,4 mm | ||
| BRF - Rotational frequency – rolling element (60 rpm) | 3,036 Hz | ||
| BPFI - Over rolling frequency on inner (60 rpm) | 9,845 Hz | ||
| Tmax - Max operating temperature | 120 °C | ||
| N lim - Mechanical Limit Speed | 2100 tr/min | ||
| Y1 - Lower axial load coefficient | 2.64 | ||
| e - Coefficient | 0.26 | ||
| C0 - Static load | 113 kN | ||
| mass | 0,637 kg | ||
| Associated sleeve reference | H309E | ||
| b - Groove width | 5,83 mm | ||
| rs - Min fillet radius | 1,1 mm | ||
| d2 - External diameter inner ring | 52,4 mm | ||
| D - External diameter | 85 mm |
| ra max - Max shaft & housing fillet radius | 1 mm | ||
| Ce - Min length fro Sleeve | 2 mm | ||
| da min - Min shoulder diameter IR | 52 mm | ||
| FTF - Rotational frequency - cage (60 rpm) | 0,421 Hz | ||
| BSF - Over rolling frequency on rolling element (60 rpm) | 6,072 Hz | ||
| BPFO - Over rolling frequency on outer ring (60 rpm) | 7,155 Hz | ||
| Tmin - Min operating temperature | -20 °C | ||
| Y2 - Upper axial load coefficient | 3.93 | ||
| Y0 - Static axial load coefficient | 2.58 | ||
| Cu - Fatigue limit load | 13,8 kN | ||
| C - Dynamic load | 121 kN | ||
| Radial clearance class | C3 | ||
| k - Hole diameter | 2,5 mm | ||
| Number of lubrication holes | 3 | ||
| D1 - Inner diameter outer ring | 78,7 mm | ||
| B - Bearing/Inner ring width | 28 mm | ||
| d - Internal diameter | 45 mm |
