| motors | 2000 series; wheel mount motor | ||
| Series | 02 : 2000 series | ||
| Mounting type | ab : wheel, 4 bolt; 108.0 [4.25] pilot dia. 13.59 [.535] dia. holes on 147.6 [5.81] dia. bolt circle. 127.0 [5.00] dia. rear mount pilot | ||
| ports | aa : .875-14 unf-2b sae o-ring ports - staggered ports | ||
| low pressure relief | 0 : none | ||
| geroler option | 1 : standard | ||
| accessories | 00 : none | ||
| special features (assembly) | 00 : none | ||
| customer identification | aa : none |
| product | m : motor | ||
| displacement | 049 : 80.6 cm3/r [ 4.92 in3/r] | ||
| output shaft | 03 : 31.75 [1.250] dia. .125;1 tapered shaft per sae j501 with 1.000-20 unef-2a threaded shaft end and slotted hex nut, 7.938 [.3125] sq x 25.40 [1.000] straight key | ||
| case flow option | 01 : .4375-20 unf-2b sae o-ring port | ||
| pressure flow option | 00 : none | ||
| seal option | 0 : standard | ||
| special features (hardware) | 00 : none | ||
| paint/packaging | ab : primer low gloss black, individual box | ||
| design code | f : sixth |
