| tube i.d. (mm) | 4 | ||
| tube o.d. (mm) | 6 | ||
| Length (m) | 25 | ||
| maximum operating pressure | 50 bar | ||
| maximum operating temperature | up to 100°c - see the graph “working pressure/working temperature” | ||
| Weight | 0.5 kg/package | ||
| number of tubes | 1 | ||
| media | semi-rigid pa: compressed air, other fluids /rigid pa: compressed air,lubricants, other fluids |
| tubing material | pa | ||
| Color | blue | ||
| weight (per unit of measure) | 0.01568 kg/m | ||
| minimum operating temperature | -40 °c | ||
| vacuum pressure rating | 755 mm-hg | ||
| bend radius | 20 mm | ||
| Application | packaging, tooling, compressed air, motion technologies, robotics, industrial machinery | ||
| specifications met | industrial: di: 2002/95/ec (rohs), 2011/65/ec; di: 97/23/ec (ped); rg: 1907/2006 (reach)/transportation: chemical performance and resistance tested according to din 74324 -1 / din 73378 / iso 7651 |
