| body | nickel plated brass | ||
| collet | nickel plated brass | ||
| Medium | compressed air | ||
| operating pressure pressure bar min to max range | 0 ... 18 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... -176 °f | ||
| oring | nbr (silicone free) | ||
| product style | pif | ||
| Series | pneufit | ||
| thread | g1/8 | ||
| thread sealant | ptfe coated |
| collar | nickel plated brass | ||
| data performance shelf life | 10 years | ||
| od tube length millimetre | 4 mm | ||
| operating pressure psi pressure psi min to max range | 0 ... 261 psi | ||
| operating temperature temperature celsius min to max range | -20 ... 80 °c | ||
| Port size | g1/8 | ||
| sealing washer | elastomers nbr (silicone free) | ||
| shape | straight | ||
| thread form | iso g |
