| Rear cover | Standard | ||
| port connection | Rectangular flange SAE metric thread | ||
| Series | Bearing diameter Ø 26mm | ||
| function | Pump | ||
| Noise level | Standard noise level | ||
| Front cover | SAE J744 101-2 (B) | ||
| Drive shaft | Splined shaft SAE J744 22-4 (13T 16/32DP) | ||
| Max. intermittent pressure | 200 bar |
| Sealing Material | NBR, WDR in FKM | ||
| Version | corrosion-resistant, pinned | ||
| model | Model G (22.5 ... 56 cm³/rev) | ||
| product | External gear unit | ||
| Housing Material | Aluminum | ||
| Direction of rotation | clockwise rotation | ||
| Maximum rotational speed | 2300 rpm | ||
| Nominal size | 63 cm³/rev |
