| Material transmitter nozzle | Wrought aluminium alloy | ||
| Material seals | NBR | ||
| Ambient temperature | 0 °C ... 60 °C | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Max. suction flow rate against atmosphere | 41,5 l/min | ||
| Operating pressure | 1 bar ... 8 bar | ||
| Ejector characteristic | Standard High suction volume | ||
| Nominal size, Laval nozzle | 0,95 mm |
| Material receiver nozzle | POM | ||
| Product weight | 1,65 g | ||
| Media temperature | 0 °C ... 60 °C | ||
| Note on operating and pilot medium | Lubricated operation not possible | ||
| Air supply time at nominal operating pressure | 0,66 s | ||
| Nominal operating pressure | 6 bar | ||
| Symbol | 00991490 | ||
| Mounting position | optional |
