| Material suction cup | PUR | ||
| Material screw-in stud | Brass | ||
| Colour | Blue | ||
| Type of mounting | Via vacuum port | ||
| Holding force at nominal operating pressure | 8,5 N | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Nominal operating pressure | -0,7 bar | ||
| Suction cup shape | Round bellows 1.5 convolutions | ||
| Mounting position | optional | ||
| Effective suction diameter | 12,4 mm | ||
| Suction cup diameter | 15 mm | ||
| Height compensator for suction cup | 5,6 mm |
| Note on materials | RoHS-compliant | ||
| Shore hardness | 60 +/- 5 | ||
| Vacuum connection | G1/8 | ||
| Product weight | 11 g | ||
| Ambient temperature | -20 °C ... 60 °C | ||
| Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] | ||
| Operating pressure | -0,95 bar ... 0 bar | ||
| Symbol | 00991485 | ||
| Position of connection | Top | ||
| Suction cup volume | 0,83 cm³ | ||
| Nominal size | 3 mm |
