| Material sub-base | Anodised wrought aluminium alloy | ||
| Pneumatic connection, port 2 | G3/8 | ||
| Type of mounting | With through-hole | ||
| Ambient temperature | 5 °C ... 50 °C | ||
| Storage temperature | -40 °C ... 80 °C | ||
| Note on operating and pilot medium | Lubricated operation not possible Maximum particle size 10 µm | ||
| Operating pressure | 0 bar ... 6 bar | ||
| Design | Connection direction at side | ||
| Mounting position | optional |
| Note on materials | Contains paint-wetting impairment substances RoHS-compliant | ||
| Pneumatic connection, port 1 | G3/8 | ||
| Product weight | 97 g | ||
| Media temperature | 5 °C ... 50 °C | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Operating medium | Inert gases Air Oxygen | ||
| Max. number of valve positions | 1 | ||
| Special characteristics | Oxygen-compatible to DIN EN 1797 | ||
| Construction width | 25 mm |
