| Material sub-base | Wrought aluminium alloy | ||
| Pneumatic connection, port 2 | M5 | ||
| Type of mounting | With through-hole Via female thread | ||
| Ambient temperature | -10 °C ... 60 °C | ||
| Media temperature | -10 °C ... 60 °C | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [6:3:4] Inert gases Air Oxygen Nitrogen | ||
| Max. number of valve positions | 1 | ||
| Mounting position | optional |
| Note on materials | RoHS-compliant | ||
| Pneumatic connection, port 1 | M5 | ||
| Product weight | 25 g | ||
| Relative air humidity | 0 - 60% Non-condensing | ||
| Storage temperature | -20 °C ... 70 °C | ||
| Note on operating and pilot medium | Lubricated operation not possible Maximum particle size 5 µm | ||
| Operating pressure | 0 bar ... 7 bar | ||
| Special characteristics | Oxygen-compatible to DIN EN 1797 | ||
| Construction width | 26 mm |
