| Material sub-base | PEEK | ||
| Mounting method for sub-base | With through-hole | ||
| Max. tightening torque for valve mounting | 0,33 Nm | ||
| Media temperature | 0 °C ... 50 °C | ||
| LABS (PWIS) conformity | VDMA24364 zone III | ||
| Note on operating and pilot medium | Observe resistance of materials that come into contact with the media | ||
| Flow direction | Non-reversible | ||
| Mounting position | optional | ||
| Nominal size | 2 mm |
| Note on materials | RoHS-compliant | ||
| Product weight | 8 g | ||
| Ambient temperature | 0 °C ... 50 °C | ||
| Storage temperature | -20 °C ... 70 °C | ||
| Corrosion resistance class CRC | 0 - No corrosion stress | ||
| Operating medium | Liquid media Gaseous media | ||
| Design | Connection direction at side | ||
| Fluid connection | M6 female thread |
