| Material manifold | Wrought aluminium alloy | ||
| Pneumatic connection, port 2 | M5 | ||
| Product weight | 270 g | ||
| LABS (PWIS) conformity | VDMA24364-B2-L | ||
| Max. number of valve positions | 6 | ||
| Grid dimension | 18 mm |
| Note on materials | RoHS-compliant | ||
| Pneumatic connection, port 1 | G1/8 | ||
| Max. tightening torque for valve mounting | 0,6 Nm | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Design | Connection direction downwards |
