| Material regulator housing | Die-cast aluminium | ||
| Pressure gauge connection | Via retaining clamp | ||
| Product weight | 611 g | ||
| Pilot medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Corrosion resistance class CRC | 0 - No corrosion stress | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Inlet pressure 1 | 0,5 bar ... 10 bar | ||
| Operating pressure | 6 bar | ||
| Symbol | 00991862 | ||
| Mounting position | optional | ||
| Construction width | 18 mm |
| Material control panel | PA | ||
| Mounting with vertical stacking | On manifold sub-base On individual sub-base | ||
| Ambient temperature | -5 °C ... 50 °C | ||
| Degree of protection | IP65 NEMA 4 | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| CE mark (see declaration of conformity) | To EU Low Voltage Directive | ||
| Pressure regulation range | 7,25 psi ... 87 psi | ||
| Selection of pressure gauge | Possible | ||
| Controller function | Output pressure constant With secondary venting | ||
| Based on standard | ISO 15407-2 |
