| Material housing | Die-cast aluminium | ||
| Electrical connection | 5-pin M12 Plugs | ||
| Number of electrical connections | 10 | ||
| Ambient temperature | -5 °C ... 50 °C | ||
| Corrosion resistance class CRC | 0 - No corrosion stress | ||
| Nominal operating voltage DC | 24 V | ||
| Max. number of valve positions | 10 with bistable valves 20 with monostable valves |
| Material cover | PA | ||
| Electrical control | Multi-pin plug | ||
| Product weight | 790 g | ||
| Degree of protection | IP65 NEMA 4 | ||
| Permissible voltage fluctuations | +/- 10 % | ||
| Max. resultant current | 10 A | ||
| Mounting position | optional |
