| Material housing | Die-cast aluminium | ||
| Electrical connection | Socket/terminal strip | ||
| Product weight | 540 g | ||
| Degree of protection | IP65 NEMA 4 | ||
| CE mark (see declaration of conformity) | To EU Low Voltage Directive | ||
| Pollution degree | 3 | ||
| Immunity to surge | 1,5 kV | ||
| Nominal operating voltage AC | 110 V | ||
| Max. number of valve positions | 16 with bistable valves 32 with monostable valves | ||
| Based on standard | EN 61984 |
| Material cover | PA | ||
| Electrical control | Multi-pin plug | ||
| Ambient temperature | -5 °C ... 50 °C | ||
| Corrosion resistance class CRC | 0 - No corrosion stress | ||
| Permissible voltage fluctuations | +/- 10 % | ||
| Current rating at 40°C | 1 A | ||
| Nominal operating voltage DC | 24 V | ||
| Max. resultant current | 6 A | ||
| Mounting position | optional |
