| Material housing | Die-cast aluminium PA | ||
| Note on materials | RoHS-compliant | ||
| Addressing range | 1 ... 31 (0) Set using AS-Interface addressing device | ||
| Electrical control | Fieldbus | ||
| Ambient temperature | -5 °C ... 50 °C | ||
| Relative air humidity | 0 - 90% | ||
| Corrosion resistance class CRC | 0 - No corrosion stress | ||
| Permissible voltage fluctuations | +/- 10 % | ||
| Max. number of inputs | 8 | ||
| Number of slaves per device | 2 | ||
| Field bus interface | Socket, M12x1, 4-pin Plug connector, M12x1, 4-pin |
| Material seals | NBR PUR | ||
| Electrical isolation fieldbus interface | Optocoupler | ||
| Electrical connection | Via CPX | ||
| Product weight | 850 g | ||
| Degree of protection | IP65 | ||
| Storage temperature | -20 °C ... 60 °C | ||
| CE mark (see declaration of conformity) | To EU EMC Directive To EU Low Voltage Directive | ||
| Nominal operating voltage DC | 24 V | ||
| Max. number of outputs | 8 | ||
| Max. number of valve coils | 8 | ||
| Mounting position | optional |
