FESTO 8032666 end plate

Name: 8032666 FESTO
Brand: FESTO
SKU: 678780-en-gbp
Price: 31.55 GBP
Availability: InStock

VABE-S1-2L-G34

£31.55

1 pcs. with 1 to 3 days delivery to United States

Specifications

Operating Pressure	0 bar ... 10 bar
Pneumatic connection	G3/4

Width	44 mm
Weight	360g

Material end plate		Die-cast aluminium
Pneumatic connection, port 5		G3/4
Pneumatic connection, port 1		G3/4
Product weight		360 g
Pilot medium		Compressed air to ISO 8573-1:2010 [7:4:4]
Storage temperature		-20 °C ... 60 °C
Note on operating and pilot medium		Lubricated operation possible (in which case lubricated operation will always be required)
CE mark (see declaration of conformity)		To EU Low Voltage Directive
Operating pressure		0 bar ... 10 bar
Exhaust-air function		Via throttle plate

Note on materials		RoHS-compliant
Pneumatic connection, port 3		G3/4
Type of mounting		Via through-hole for M6 screw
Ambient temperature		-10 °C ... 50 °C
Media temperature		-10 °C ... 50 °C
Corrosion resistance class CRC		0 - No corrosion stress
Operating medium		Compressed air to ISO 8573-1:2010 [7:4:4]
Suitability for vacuum		yes
Based on standard		ISO 5599-1
Construction width		44 mm
