| Rolling element frequency (60 t./min.) | 4,923 Hz | ||
| Inner ring frequency (60 t./min.) | 5,379 Hz | ||
| Recommended tightening torque for set screw | 8 N-m | ||
| Operating temperature min. | -20 °C | ||
| C - Dynamic load rating | 31,85 kN | ||
| S - Dist. cent. of raceway to face IR on side opp. lock. device | 19 mm | ||
| m - Distance to set screw | 8 mm | ||
| C1 - Distance center of OR to center of lubrication zone | 6,8 mm | ||
| Brand | SNR |
| Cage frequency (60 t./min.) | 0,402 Hz | ||
| Outer ring frequency (60 t./min.) | 3,621 Hz | ||
| Operating temperature max. | 200 °C | ||
| C0 - Static load rating | 20,8 kN | ||
| SW - Wrench size | 3,969 mm | ||
| r - Radius Inner Ring | 1.10 | ||
| G - Set screw size | 5/16-24UNF | ||
| C - Width of Outer Ring | 22 mm |
