| Suitable for use with food | See supplementary material information | ||
| Ambient temperature with moving cable | -20 °C ... 70 °C | ||
| Material housing | Wrought aluminium alloy Nickel-plated brass PP TPE-O TPE-U(PU) High-alloy stainless steel | ||
| Mounting position | optional | ||
| Type of mounting | Clamped | ||
| Material cable sheath | TPE-O | ||
| Connection outlet orientation | In-line | ||
| Reverse polarity protection | For all electrical connections | ||
| Operational voltage range DC | 10 V ... 30 V | ||
| Short circuit current rating | Pulsed | ||
| Max. switching capacity DC | 6 W | ||
| Switch-off time | ≤ 0,5 ms | ||
| Switching element function | N/O contact | ||
| Ambient temperature | -20 °C ... 70 °C | ||
| Measured variable | Position | ||
| CE mark (see declaration of conformity) | To EU EMC Directive | ||
| Symbol | 00991152 | ||
| Design | Block design |
| Degree of protection | IP65 IP68 To IEC 60529 | ||
| Switching status indication | Yellow LED | ||
| Product weight | 65,9 g | ||
| Tightening torque | 1,2 Nm | ||
| Wire ends | Wire end sleeve | ||
| Cable length | 5 m | ||
| Electrical connection | 3-wire Cable | ||
| Residual ripple | 10 % | ||
| Overload protection | Available | ||
| Voltage drop | < 1,8 V | ||
| Max. output current | 200 mA | ||
| Switch-on time | ≤ 0,5 ms | ||
| Switching output | PNP | ||
| Measuring principle | Magneto-inductive | ||
| Note on materials | Free of halogen | ||
| Approval | RCM trademark | ||
| Based on standard | EN 60947-5-2 |
