| Material nut | Galvanised steel | ||
| Note on materials | RoHS-compliant | ||
| Ambient temperature | 0 °C ... 60 °C | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Nominal size | 1,9 mm |
| Material housing | Aluminium | ||
| Pneumatic connection, port 1 | For tubing outer diameter of 4 mm | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Operating pressure complete temperature range | -0,95 bar ... 10 bar |
