| Language code f. test certif. | without | ||
| Paint/top coat | without | ||
| Version_2 | Standard | ||
| Type of Operation | Pump, open loop | ||
| Control device | DR remote-controlled | ||
| Direction of rotation | right-hand (view on shaft end) | ||
| Shaft End | Spline with run-out | ||
| Service line connections | B flan s metr, S flan s metr | ||
| Connector for solenoids | without | ||
| Operating pressure | 315 bar | ||
| Adjustment max. displacement | Variabel | ||
| Adjustment min. displacement | Variabel | ||
| Min. Output Flow | 0.0 l/min | ||
| Approval Company (external) | No |
| Paint/Primer | without | ||
| Version_1 | Standard | ||
| Product (Axial piston unit) | A10VZ | ||
| Size (Displacement) | 18 cm³ | ||
| Series | Series 1, Index 0 | ||
| Sealing Material | FKM (Standard) | ||
| Mounting flange | ISO 3019-1 (SAE), 2 bolt | ||
| Through drive | without through drive | ||
| Speed of Rotation | 3300 rpm | ||
| Max. Displacement | 18.0 cm³ | ||
| Min. Displacement | 0.0 cm³ | ||
| Max. Output Flow | 59.4 l/min | ||
| Internal drain line | No | ||
| Test certificate | without |
