REXROTH R902230092 axial-piston pump

A7VO28DR/63R-NPB01 *GO2EU*

£3,879.24 £6,140.25 -36%
available with 7 to 15 days delivery to United States

Specifications

  • Robust high pressure pump for universal use
  • Size 28 … 500
  • Nominal pressure 350 bar
  • Maximum pressure 400 bar
  • Open circuit

Seal NBR, WDR-FKM (Std up to NG160)
Weight 18Kg
Stroke limiter (from Size 250) without
Stroke limiter Wthout
Pres.control w. Load-Sensing without
Paint/top coat without
Language code f. test certif. without
Approval Company (external) Standard without acceptance
Port B SAE 3/4" mount.thr. M10
Port T1 GE 6 – SM open
Port A Without
Working Press.at Max.Outp.Flow 50 bar
Limitation of displacement ohne (Standard)
max. Pump Speed 3,150
Max. Output Flow 85.0 l/min
Port plate for service lines SAE A/B and S rear
Shaft end size Shaft end AS8X7X40
Sealing Material NBR, WDR-FKM (Std up to NG160)
Series 63
Control device Pressure controller
Type of Operation Open circuit
Remote pressure contol Without
elec. adjustm.(up to size 160) ohne
Remote LR (from size250) Wthout
Paint/Primer RAL 9005 jet black
Test certificate without
Port U M16x1.5 plugged
Port X1 without
Suction Connection Port S SAE 1 1/2" mount.thr. M12
solenoid design without
Working Press.at Min.Outp.Flow 50 bar
Adjustment of pressure control 350
Min. Output Flow 0.0 l/min
Working Pressure max. 350.0 bar
Mounting flange 4-hole ISO 3019-2
Shaft End Parallel keyed DIN6885
Direction of rotation right-hand (view on shaft end)
Pressure Cut-Off Without
Size (Displacement) 28 cm³
Product (Axial piston unit) A7VO
£3,879.24
Stock available
Part number R902230092
Manufacturer REXROTH
Quantity Unit Price
1+ £3,879.24
