1)
Lube nipple, hydraulic type A as per DIN 71412
| AV | 46 | min. | |
| CN (Matching pivot pin ⌀ m6) | 40 | H7 | |
| EN | 40 | ||
| KK | M33x2 | ||
| LF | 39 |
| CH | 97 | JS15 | |
| EF | 50 | max. | |
| Eu | 34 | max. | |
| Clamping screw (ISO 4762-10.9) | M10x30 | ||
| N | 47 | mm |
| MA | 59 | Nm |
| m (Add mass for basis cylinder weight) | 2.10 | kg |
