| activation | electrically | ||
| working pressure max | 10 bar | ||
| operational voltage ac at 60 hz | 110 v | ||
| min. ambient temperature | 10 °c | ||
| min. medium temperature | 10 °c | ||
| Medium | compressed air | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| holding power ac 50 hz | 5 va | ||
| Duty cycle | 100 % | ||
| protection class with connection | ip65 | ||
| Housing Material | polyphenylene sulfide |
| working pressure min. | 2 bar | ||
| operational voltage ac at 50 hz | 110 v | ||
| frame size | iso 3 | ||
| max. ambient temperature | 120 °c | ||
| max. medium temperature | 120 °c | ||
| max. particle size | 5 µm | ||
| oil content of compressed air max. | 5 mg/m³ | ||
| holding power ac 60 hz | 4.2 va | ||
| connector standard | cnomo / nfe 49-003-1 | ||
| Weight | 0.18 kg | ||
| seal material | fluorocaoutchouc |
