| Material hand lever | polyamide | ||
| seal material | acrylonitrile butadiene rubber | ||
| Weight | 0.04 kg | ||
| nominal flow qn 1 to 2 | 550 l/min | ||
| working pressure min. | -1 bar | ||
| min. medium temperature | -20 °c | ||
| min. ambient temperature | -20 °c | ||
| compressed air connection 2 | Ø 8 | ||
| compressed air connection 1 | g 1/4 | ||
| Type | poppet valve |
| Material release ring | polyamide | ||
| Housing Material | polyamide | ||
| delivery unit | 5 piece | ||
| working pressure max | 16 bar | ||
| max. medium temperature | 80 °c | ||
| max. ambient temperature | 80 °c | ||
| compressed air connection type 2 | push-in fitting | ||
| compressed air connection type 1 | external thread | ||
| Medium | compressed air |
