REXROTH R183536261 roller guide rail carbon steel

Name: R183536261 REXROTH
Brand: REXROTH
SKU: 432868-en-gbp
Price: 7610.71 GBP
Availability: SoldOut

RSA-125-SNS-P-MA-SC

£7,610.71 /m ~~£9,490.17~~ /m -19%

Limited stock only available on quotation

Specifications

Series (R1835)	SNS with cover strip made of steel R1835...6
Size (36)	125 size

Accuracy class (2)	P Precision Accuracy Level
Sections (61)	One-piece

Roller guide rail with cover strip and front thread holes.
Retaining with screws and washers (included).

D	49	mm
N₆	74.5 mm ±0.5
N₈	38	mm
ØS₅	33	mm
T_{1 min} (with a shortfall of T_{1 min} Front thread not possible. Secure the cover strip! Observe the mounting instructions! )	40	mm
n_B	22

Dimension H₂ with cover strip (with cover strip 0.3 mm)	115.30	mm
N₇	91	mm
N₉	4.80	mm
T	120	mm
T_{1 s} (Preferred dimension T_1S with tolerance +1/-1.5 )	56.50	mm

m	75.60	kg
Operating conditions	Operating conditions
Permissible ambient temperature (min ... max) (Brief peaks up to 100 °C are permitted. For even lower sub-zero temperatures, please consult us. )	-10 °C ... +80 °C
