a)
Lubricating hole sealed with plastic cap
| H3 | 10 | mm | |
| L | 59 | mm | |
| D | 40 | mm | |
| E1 | 60 mm ±0.15 | ||
| E3 | 64 | mm | |
| H | 30 | mm | |
| H1 | 60 | mm | |
| N1 | 29 | mm | |
| S | 8.40 | ||
| S2 | 6 | ||
| V | 6.50 | mm |
| H4 | 20 | mm | |
| l3 | 21 | ||
| A | 78 | mm | |
| E2 | 40 mm ±0.15 | ||
| E4 | 17 | mm | |
| Tolerance for H (Clamped (fastened) in relation to Ø d.) | + 8 - 16 |
||
| m | 39 mm ±0.01 | ||
| N2 | 22 | mm | |
| S1 | M10 | ||
| SW | 5 |
| amax | 150 | m/s² | |
| m | 0.63 | kg | |
| Breakaway force | 7 | N | |
| Operating conditions | Operating conditions |
| vmax | 5 | m/s | |
| FR (Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. ) | 3 | N | |
| Radial clearance | Comes clamped to h5 shaft (lower limit) and set to zero clearance | ||
| Permissible ambient temperature (min ... max) | -20 °C ... +80 °C |
