R165169360 Bosch Rexroth

REXROTH R165169360 ball runner block resist cr

Name: R165169360 REXROTH
Brand: REXROTH
SKU: 110828-en-gbp
Price: 911.21 GBP
Availability: InStock

KWC-065-FNS-C0-H-2

£911.21

available with 7 to 15 days delivery to United States

Find your match! Click to explore guide rails that pair with this runner block

Specifications

Area of application: For high rigidity requirements
Attachments on the Ball Runner Block can be mounted from above and below
Significantly reduced frictional oscillations and low friction level, particularly under external load
Maximum precision
Patented entry zone increases the travel accuracy up to a factor of six

Ball runner block Resist CR with corrosion-resistant coating, matt silver finish, hard chrome plated

Series (R1651)	Flange, normal, standard height R1651
Size (6)	65 size
Preload class (9)	C0 Without preload (clearance)

Accuracy class (3)	H Hight Accuracy Level
Seals (60)	SS Standard seal without ball chain

Dimensions
Technical data

^a) Recommended position for pin holes (dimension E₄ see general technical notes and information in the "Installation" section).
Rough-drilled holes may be present here from manufacturing. These may be bored open.
^b) Lube nipple, size 55:
Hydraulic-type lube nipple DIN 71412-B M6x8, B₂ = 16 mm
Lube nipple, size 65:
Hydraulic-type lube nipple DIN 71412-B M8x1x8, B₂ = 16 mm
When using different lube nipples, pay attention to the screw-in depth of 8 mm!
The lube nipple is included in the scope of delivery (not installed).
Connection is possible on end-face.
^c) Sealing plugs may be present here from manufacturing. Remove these prior to mounting.
^d) Size 65

A	170	mm
A₂	63	mm
B	188 mm +0.5
E₁	142	mm
E₃	82	mm
E_8.1	100	mm
E_9.1	53.50	mm
H₁	76	mm
Dimension H₂ without cover strip	59.85	mm
N₁	23	mm
N₆	38.5 mm ±0.5
S₂	M16
S₉	M4x7
V₁	15	mm

A₁	85	mm
A₃	53.50	mm
B₁	139.60	mm
E₂	110	mm
E₈	76	mm
E₉	11	mm
H	90	mm
Dimension H₂ with cover strip	60.15	mm
K₃	16	mm
N₂	14	mm
S₁	14.60	mm
ØS₅	18	mm
T	150	mm

a_max (If F_comb > 2.8 • F_pr : a_max = 50 m/s²)	250	m/s²
m	10.25	kg
Operating conditions	Operating conditions
Permissible ambient temperature (min ... max) (Up to 100 °C permissible for short periods. For operation at negative temperatures, please consult us. )	-10 °C ... +80 °C
