| Size | 20 x 5R; 25 x 5R/10R | ||
| Dimensions | 62 mm -0.013 | ||
| Dimensions | 68 | d | |
| Dimensions | 20 | d | |
| Dimensions | 104 | d | |
| Dimensions | 44 | d | |
| Dimensions | 100 | d | |
| Dimensions | 80 | d |
| Dimensions | 25 mm -0.01 | ||
| Dimensions | 89 | d | |
| Dimensions | 16 | d | |
| Dimensions | 36 | d | |
| Dimensions | 80 | d | |
| Dimensions | 120 | d | |
| Dimensions | 11 | d |
| Size | 20 x 5R; 25 x 5R/10R | ||
| C0 | 119,200 | N | |
| MAG | 8 | Nm | |
| Rfb | 450 | N/μm | |
| nmax (Guideline values for low load on bearing, good heat dissipation, and suitable grease lubricants with low consistency ) | 6,900 | rpm |
| C | 74,200 | N | |
| MA | 38 | Nm | |
| MRb (Measured at 50 min-1) | 1.10 | Nm | |
| Rkl | 160 | Nm/mrad | |
| Mass | 3.50 | kg |
