1)
Centering diameter D for motor flange
2)
Fastening thread S3 x T3 for motor flange
3)
only for material number R1595 330 20
| Ball bearing | 30 | d | |
| Ball bearing | 28 | d | |
| B2 | 12.50 | mm | |
| D22 | 25 | ||
| H2 | 111 | mm | |
| M1 | 90 mm ±0.015 | ||
| M3 | 150 | ||
| L2 | 73 | mm | |
| l4 | 20 | ||
| L22 | 50 | ||
| S2 | 11.70 | ||
| S4 | M14 | ||
| T4 | 22 | ||
| V2 | 65 | mm |
| Ball bearing | 80 | d | |
| B1 | 65 | mm | |
| B3 | 40 | mm | |
| H1 | 56 mm ±0.015 | ||
| H3 | 33 | mm | |
| M2 | 116 | ||
| L1 | 45 | mm | |
| l3 | 20 | ||
| L20 | 93 | ||
| S1 | 12.50 | mm | |
| S3 | M10 | ||
| T3 | 20 | mm | |
| V1 | 100 | mm |
| Size | 40x5 | ||
| Ball bearing (Load ratings (axial)) | 64,000 | C | |
| Pillow block unit assembly | 6.31 | m |
| Ball bearing (Load ratings (axial)) | 29,000 | C | |
| Slotted nut | 32 | M<sub>A</sub> |
