1)
Countersink for O-ring 7 x 1.5
| Size | 40 x 5R x 3,5 40 x 10R x 6 40 x 20R x 6 40 x 40R x 6 |
||
| Hex socket cap screw (for bolting from below) | M14 | ||
| B | 60 mm ±0.01 | ||
| E1 | 90 | mm | |
| H | 59 mm ±0.01 | ||
| H2 | 10 | mm | |
| S | 14.50 | ||
| T1 | 24 | mm | |
| T3 | 155 | mm |
| Mass | 4.32 | g | |
| A | 180 | mm | |
| ØD1 | 63 | H<sub>6</sub> | |
| E2 | 120 | mm | |
| H1 | 105 | mm | |
| HA5 | 18 | ||
| S1 | M16 | ||
| T2 | 20 | mm | |
| Clamping length | 86 | L |
