REXROTH R107623020 linear-set

Name: R107623020 REXROTH
Brand: REXROTH
SKU: 433576-en-gbp
Price: 1546.65 GBP
Availability: InStock

LSRE-30-DD

£1,546.65

available with 7 to 15 days delivery to United States

Specifications

Type (LS)	Linear sets Open, adjustable, R1076
Series (R)	Radial, open
Housing (E)	Adjustable

Shaft diameter (30)	30 Shaft diameter
Seals (DD)	With two seals

^a) Center lubricating hole
^b) Lubricating hole M8 x 1 sealed with plastic cap

D	60	mm
E₁	75 mm ±0.5
H	48	mm
H₁	75	mm
L	130	mm
O (ISO 4762–8.8 cylinder head bolts, recommendation applies for bolting in steel or cast iron threads. )	M10x30
SW	5
W (Minimum size in relation to shaft diameter d.)	14	mm

A	140	mm
E₂	108 mm ±0.5
Tolerance for H (Clamped (fastened) based on nominal shaft dimension d.)	+ 15 - 5
H₂	18	mm
L₁	84 mm +0.5
S	11
V	16	mm

v_max	2	m/s
F_R	8	N
Radial clearance	Comes with an h5 shaft (lower limit) and set to zero clearance
Permissible ambient temperature (min ... max) (100 °C for a short period)	-20 °C ... +80 °C
