REXROTH R106861640 linear-set

Name: R106861640 REXROTH
Brand: REXROTH
SKU: 288395-en-gbp
Price: 100.48 GBP
Availability: InStock

LSSOE-A-16-DD

£100.48

50+ pcs. with 1 to 3 days delivery to United Kingdom

Specifications

Type (LS)	Linear sets Open, adjustable, R1068
Material (housing) (S)	Steel
Form (OE)	Open, Adjustable

Series (A)	Super a (with misalignment compensation)
Shaft diameter (16)	16 Shaft diameter
Seals (DD)	With two seals

W (Minimum size in relation to Ø d.)	9	mm
SW	2.50
L	36	mm
Tolerance for H (Clamped (fastened) in relation to Ø d.)	+ 8 - 16
A (Tolerance ISO 8062-3 - DCTG 9.)	50	mm
D	26	mm
E₁	40 mm ±0.15
B (Tolerance ISO 8062-3 - DCTG 9.)	35

Permissible ambient temperature (min ... max)	-10 °C ... +80 °C
Radial clearance	Comes clamped to h5 shaft (lower limit) and set to zero clearance
F_R (Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. )	1	N
v_max (Speeds of up to 5 m/s possible. Service life is limited by heightened wear to plastic parts. Tests have shown total travel from 50 • 10⁵ m to 100 • 10⁵ m without failure. )	3	m/s
