REXROTH R106722500 linear-set

Name: R106722500 REXROTH
Brand: REXROTH
SKU: 288370-en-gbp
Price: 119.71 GBP
Availability: InStock

LSGO-M-25-DD

£119.71

16 pcs. with 1 to 3 days delivery to United States

Specifications

Shaft diameter (25)	25 Shaft diameter
Seals (DD)	With two seals

D	40	mm
A (Tolerance ISO 8062-3 - DCTG 9.)	74	mm
B₁	40	mm
E₂	40 mm ±0.15
Tolerance for H (Clamped (fastened) in relation to Ø d.)	+ 5 - 19
L	58	mm
V (Tolerance ISO 8062-3 - DCTG 9.)	9	mm

A	60	mm
B (Tolerance ISO 8062-3 - DCTG 9.)	54
E₁	60 mm ±0.15
H	30	mm
H₂ (Tolerance ISO 8062-3 - DCTG 9.)	51	mm
S	5.50
W (Minimum size in relation to Ø d.)	12.50	mm

v_max	2.50	m/s
F_R (Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. )	7	N
Shaft radial clearance h6	+ 38 + 4
Permissible ambient temperature (min ... max) (for standard Linear Bushings without wiper seals)	-10 °C ... +100 °C
