REXROTH R106022020 linear-set

Name: R106022020 REXROTH
Brand: REXROTH
SKU: 29722-en-gbp
Price: 47.76 GBP
Availability: InStock

LSK-20-DD-NR

£47.76 ~~£66.63~~ -28%

32 pcs. with 1 to 3 days delivery to United States

Specifications

Type (LS)	Linear sets Adjustable Normal or stainless, R1060
Series (K)	Plastic (with segmental linear bushing)
Form	Closed

B	23
H (In relation to nominal shaft dimension "d")	25 mm ±0.08
L	38	mm
L₁	30 mm
V	10.50	mm

a_max	150	m/s²
m	0.08	kg
Breakaway force (Frictional drags generated by Linear Bushings with seals on both ends when not under radial load. This depends on speed and lubrication. )	5	N
Operating conditions	Operating conditions

v_max	3	m/s
F_R (Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. )	2.50	N
Radial clearance	Comes clamped to h5 shaft (lower limit) and set to zero clearance
Permissible ambient temperature (min ... max)	-10 °C ... +65 °C
