| V | 50 | mm | |
| e | 37 | ||
| m | 8.30 | ||
| O2 (DIN6912-8.8, only applicable for bolting with steel or cast iron threads.) | M6x16 | ||
| T | 8.60 | mm | |
| V | 6 | mm |
| A | 52 | mm | |
| H (Measured with gauging shaft, nominal dimension d and length about 50 mm.) | 32 mm ±0.01 | ||
| O1 (DIN 6912-8.8) | M6x25 | ||
| T (For general requirements.) | 150 | mm | |
| U1 (DIN 7980, discontinued. Spring washer commercially available.) | 6 | mm |
| L | 600 | mm | |
| m | 0.90 | kg |
| Tolerance for L | - 500 µm - 1500 µm |
