| A | 52 | mm | |
| H (Measured with gauging shaft, nominal dimension "d" and length about 50 mm. Up to 1,800 mm length with parallelism of 0.1 mm available upon request. ) | 32 mm ±0.1 | ||
| O1 (DIN 6912-8.8) | M6x25 | ||
| T | 180 | mm | |
| V | 6 | mm |
| e | 40 | ||
| m | 8.30 | ||
| O2 (DIN 6912-8.8) | M6 | ||
| T | 7 | mm |
| L | 1,800 | mm | |
| m | 1.30 | kg |
| Tolerance for L | - 500 µm - 1500 µm |
